Internal component packs

One kit, multiple configurations.

The ProtoBrix Internal Components Kit includes a complete range of precision inserts that connect your catheter system to the U-Handle actuator, allowing instant adaptation to different catheter diameters during testing and validation.

Available in two sets: 6 Fr to 14 Fr and 14 Fr to 24 Fr.
Each kit provides all the internal parts needed to configure your U-Handle across multiple prototype sizes.

Perfect for labs managing several projects or iterating rapidly on different delivery system designs.

Key Features

• Full adaptability: Instantly adjust your U-Handle for a wide range of catheter diameters without redesigning or retooling.

• Two kit options:

  • Small range: 6 Fr to 14 Fr

  • Large range: 14 Fr to 24 Fr

• Seamless integration: Designed for precise, secure connection between catheter shafts and the U-Handle’s dual actuator system.

• Time-saving modularity: Switch between component sizes in minutes — ideal for R&D environments requiring flexibility and repeatability.

• High-precision manufacturing: Tight tolerances guarantee smooth mechanical performance and consistent test results.

Why It Matters

Instead of sourcing multiple single components, the Internal Components Kit gives you all the options you need to prototype faster and smarter.

It keeps your bench testing flexible, your development cycle shorter, and your budget under control — while maintaining the reliability expected from ProtoBrix tools.

Specifications

• Compatible product: ProtoBrix U-Handle

• Kit options:

  • 6 Fr – 14 Fr

  • 14 Fr – 24 Fr

• Material: High-precision polymer

• Configuration: Set of modular inserts with individual identification

• Delivery: Ships within 2 days
